VERSOLEX® 110 Flexible Single Core
VERSOLEX® 110 Flexible Single Core
VERSOLEX
Single core flexible copper conductors, 0.6/1kV X-HF-110 insulated and TPE (Rubber) sheathed to AS/NZS 5000.1. 110°C maximum operating temperature.
Read moreVERSOLEX 110 Flexible 10mm2 Cu Black
Nexans ref. BESX01AA001CXNA
- Packaging: Cut to length (m)
- Approximate weight: 14.0 kg/100m
- Conductor cross-section: 10 mm²
- Maximum diameter of wires: 0.21 mm
- Nominal overall diameter: 8.6 mm
- Maximum Pulling Tension: 0.2 kN
- Minimum Bend Radius - During Installation (under Tension): 52 mm
- Minimum Bend Radius - Installed: 34 mm
VERSOLEX 110 Flexible 16mm2 Cu Black
Nexans ref. BESX02AA001CXNA - Country ref. BESX02AA001CXNA
- Packaging: Cut to length (m)
- Approximate weight: 20.0 kg/100m
- Conductor cross-section: 16 mm²
- Maximum diameter of wires: 0.21 mm
- Nominal overall diameter: 9.8 mm
- Maximum Pulling Tension: 0.3 kN
- Minimum Bend Radius - During Installation (under Tension): 59 mm
- Minimum Bend Radius - Installed: 39 mm
VERSOLEX 110 Flexible 25mm2 Cu Black
Nexans ref. BESX03AA001CXNA - Country ref. BESX03AA001CXNA
- Packaging: Cut to length (m)
- Approximate weight: 30.0 kg/100m
- Conductor cross-section: 25 mm²
- Maximum diameter of wires: 0.21 mm
- Nominal overall diameter: 11.3 mm
- Maximum Pulling Tension: 0.5 kN
- Minimum Bend Radius - During Installation (under Tension): 68 mm
- Minimum Bend Radius - Installed: 45 mm
VERSOLEX 110 Flexible 35mm2 Cu Black
Nexans ref. BESX04AA001CXNA - Country ref. BESX04AA001CXNA
- Packaging: Cut to length (m)
- Approximate weight: 39.0 kg/100m
- Conductor cross-section: 35 mm²
- Maximum diameter of wires: 0.21 mm
- Nominal overall diameter: 12.5 mm
- Maximum Pulling Tension: 0.7 kN
- Minimum Bend Radius - During Installation (under Tension): 75 mm
- Minimum Bend Radius - Installed: 50 mm
VERSOLEX 110 Flexible 50mm2 Cu Black
Nexans ref. BESX05AA001CXNA - Country ref. BESX05AA001CXNA
- Packaging: Cut to length (m)
- Approximate weight: 54.0 kg/100m
- Conductor cross-section: 50 mm²
- Maximum diameter of wires: 0.31 mm
- Nominal overall diameter: 14.1 mm
- Maximum Pulling Tension: 1 kN
- Minimum Bend Radius - During Installation (under Tension): 85 mm
- Minimum Bend Radius - Installed: 56 mm
VERSOLEX 110 Flexible 70mm2 Cu Black
Nexans ref. BESX63AA001CXNA - Country ref. BESX63AA001CXNA
- Packaging: Cut to length (m)
- Approximate weight: 75.0 kg/100m
- Conductor cross-section: 70 mm²
- Maximum diameter of wires: 0.51 mm
- Nominal overall diameter: 16.2 mm
- Maximum Pulling Tension: 1.4 kN
- Minimum Bend Radius - During Installation (under Tension): 97 mm
- Minimum Bend Radius - Installed: 65 mm
VERSOLEX 110 Flexible 95mm2 Cu Black
Nexans ref. BESX64AA001CXNA - Country ref. BESX64AA001CXNA
- Packaging: Cut to length (m)
- Approximate weight: 99.0 kg/100m
- Conductor cross-section: 95 mm²
- Maximum diameter of wires: 0.51 mm
- Nominal overall diameter: 18.1 mm
- Maximum Pulling Tension: 1.9 kN
- Minimum Bend Radius - During Installation (under Tension): 109 mm
- Minimum Bend Radius - Installed: 72 mm
VERSOLEX 110 Flexible 120mm2 Cu Black
Nexans ref. BESE87AA001CXNA - Country ref. BESE87AA001CXNA
- Packaging: Cut to length (m)
- Approximate weight: 125.0 kg/100m
- Conductor cross-section: 120 mm²
- Maximum diameter of wires: 0.51 mm
- Nominal overall diameter: 20.6 mm
- Maximum Pulling Tension: 2.4 kN
- Minimum Bend Radius - During Installation (under Tension): 124 mm
- Minimum Bend Radius - Installed: 82 mm
VERSOLEX 110 Flexible 150mm2 Cu Black
Nexans ref. BESE88AA001CXNA - Country ref. BESE88AA001CXNA
- Packaging: Cut to length (m)
- Approximate weight: 151.0 kg/100m
- Conductor cross-section: 150 mm²
- Maximum diameter of wires: 0.51 mm
- Nominal overall diameter: 22.5 mm
- Maximum Pulling Tension: 3 kN
- Minimum Bend Radius - During Installation (under Tension): 135 mm
- Minimum Bend Radius - Installed: 90 mm
VERSOLEX 110 Flexible 185mm2 Cu Black
Nexans ref. BESE89AA001CXNA - Country ref. BESE89AA001CXNA
- Packaging: Cut to length (m)
- Approximate weight: 180.0 kg/100m
- Conductor cross-section: 185 mm²
- Maximum diameter of wires: 0.51 mm
- Nominal overall diameter: 24.8 mm
- Maximum Pulling Tension: 3.7 kN
- Minimum Bend Radius - During Installation (under Tension): 149 mm
- Minimum Bend Radius - Installed: 99 mm
VERSOLEX 110 Flexible 240mm2 Cu Black
Nexans ref. BESE90AA001CXNA - Country ref. BESE90AA001CXNA
- Packaging: Cut to length (m)
- Approximate weight: 241.0 kg/100m
- Conductor cross-section: 240 mm²
- Maximum diameter of wires: 0.51 mm
- Nominal overall diameter: 28.0 mm
- Maximum Pulling Tension: 4.8 kN
- Minimum Bend Radius - During Installation (under Tension): 252 mm
- Minimum Bend Radius - Installed: 168 mm
VERSOLEX 110 Flexible 300mm2 Cu Black
Nexans ref. BESE91AA001CXNA - Country ref. BESE91AA001CXNA
- Packaging: Cut to length (m)
- Approximate weight: 292.0 kg/100m
- Conductor cross-section: 300 mm²
- Maximum diameter of wires: 0.51 mm
- Nominal overall diameter: 30.8 mm
- Maximum Pulling Tension: 6 kN
- Minimum Bend Radius - During Installation (under Tension): 277 mm
- Minimum Bend Radius - Installed: 185 mm
VERSOLEX 110 Flexible 400mm2 Cu Black
Nexans ref. BESE92AA001CXNA - Country ref. BESE92AA001CXNA
- Packaging: Cut to length (m)
- Approximate weight: 391.0 kg/100m
- Conductor cross-section: 400 mm²
- Maximum diameter of wires: 0.51 mm
- Nominal overall diameter: 35.5 mm
- Maximum Pulling Tension: 8 kN
- Minimum Bend Radius - During Installation (under Tension): 320 mm
- Minimum Bend Radius - Installed: 213 mm
VERSOLEX 110 Flexible 500mm2 Cu Black
Nexans ref. BESE93AA001CXNA - Country ref. BESE93AA001CXNA
- Packaging: Cut to length (m)
- Approximate weight: 500.0 kg/100m
- Conductor cross-section: 500 mm²
- Maximum diameter of wires: 0.51 mm
- Nominal overall diameter: 40.0 mm
- Maximum Pulling Tension: 10 kN
- Minimum Bend Radius - During Installation (under Tension): 360 mm
- Minimum Bend Radius - Installed: 240 mm
VERSOLEX 110 Flexible 630mm2 Cu Black
Nexans ref. BESE94AA001CXNA - Country ref. BESE94AA001CXNA
- Packaging: Cut to length (m)
- Approximate weight: 630.0 kg/100m
- Conductor cross-section: 630 mm²
- Maximum diameter of wires: 0.61 mm
- Nominal overall diameter: 44.6 mm
- Maximum Pulling Tension: 12.6 kN
- Minimum Bend Radius - During Installation (under Tension): 400 mm
- Minimum Bend Radius - Installed: 270 mm
Description
Description
Standards
-
ProductAS/NZS 5000.1
VERSOLEX® 110 Flexible Single Core is Nexans range of premium flexible power cables suited to a wide range of commercial and industrial applications. Robust and durable, VERSOLEX is the first choice for flexibility and reliability.
Specifications
- PVC components meet Best Practice Guidelines for PVC in the built environment.
- Available in Low Smoke Zero Halogen (low fire hazard). See ENVIROLEX - Low Fire Hazard.
- In systems intended to operate continuously at 90°C maximum operating temperature, Nexans Envirolex - Low Fire Hazard is recommended. Note that designing and operating a system continuously at maximum operating temperature is unlikely to be energy efficient over the life of the asset.
Application
- For fixed application.
- Submersible up to 500m
- Maximum operating temperature 110°C
Features & Benefits
- 0.6/1kV cables,
- Flexible X-HF-110 insulated to AS/NZS5000.1
- TPE sheathed
- Copper flexible conductors.
- Submersible up to 500m
Characteristics
Characteristics
Construction characteristics
Construction characteristics
Colour
Black
Conductor flexibility
Class 5
Conductor material
Copper
Conductor shape
Circular
Insulation
X-HF-110
Outer sheath
TPE
Electrical characteristics
Electrical characteristics
Rated Voltage Uo/U (Um)
0,6/1 kV
Usage characteristics
Usage characteristics
Maximum operating temperature
110 °C
Resources
Resources
VERSOLEX® 110 Flexible Single Core 110°C - Current carrying capacity table three phase (in Amps)
Insulation type: R-HF-110, R-E-110 OR X-HF-110
Maximum conductor temperature: 110°C
Reference ambient temperature: 40°C IN AIR, 25°C IN GROUND
| Conductor cross-section |
|
|
|
|
|
|
|
|
|
|---|---|---|---|---|---|---|---|---|---|
| mm² | Cu | Cu | Cu | Cu | Cu | Cu | Cu | Cu | Cu |
| 1.0 | 25.0 | 22.0 | 21.0 | 18.0 | 15.0 | 10.0 | 28.0 | 21.0 | 25.0 |
| 1.5 | 31.0 | 27.0 | 26.0 | 23.0 | 19.0 | 13.0 | 35.0 | 26.0 | 31.0 |
| 2.5 | 42.0 | 36.0 | 34.0 | 31.0 | 24.0 | 17.0 | 46.0 | 34.0 | 40.0 |
| 4.0 | 55.0 | 48.0 | 45.0 | 40.0 | 32.0 | 23.0 | 59.0 | 44.0 | 52.0 |
| 6.0 | 70.0 | 61.0 | 57.0 | 50.0 | 40.0 | 29.0 | 74.0 | 55.0 | 65.0 |
| 10.0 | 99.0 | 85.0 | 80.0 | 70.0 | 56.0 | 40.0 | 99.0 | 76.0 | 87.0 |
| 16.0 | 130.0 | 112.0 | 105.0 | 91.0 | 73.0 | 53.0 | 127.0 | 97.0 | 113.0 |
| 25.0 | 173.0 | 149.0 | 139.0 | 121.0 | 97.0 | 70.0 | 162.0 | 125.0 | 143.0 |
| 35.0 | 214.0 | 184.0 | 172.0 | 148.0 | 118.0 | 86.0 | 196.0 | 151.0 | 176.0 |
| 50.0 | 270.0 | 233.0 | 217.0 | 190.0 | 152.0 | 0.0 | 238.0 | 188.0 | 213.0 |
| 70.0 | 340.0 | 292.0 | 273.0 | 234.0 | 187.0 | 0.0 | 290.0 | 229.0 | 257.0 |
| 95.0 | 410.0 | 353.0 | 329.0 | 277.0 | 221.0 | 0.0 | 338.0 | 268.0 | 306.0 |
| 120.0 | 487.0 | 418.0 | 390.0 | 331.0 | 265.0 | 0.0 | 388.0 | 316.0 | 350.0 |
| 150.0 | 562.0 | 482.0 | 450.0 | 378.0 | 302.0 | 0.0 | 438.0 | 357.0 | 403.0 |
| 185.0 | 644.0 | 553.0 | 516.0 | 438.0 | 350.0 | 0.0 | 489.0 | 404.0 | 448.0 |
| 240.0 | 775.0 | 665.0 | 620.0 | 538.0 | 430.0 | 0.0 | 569.0 | 481.0 | 534.0 |
| 300.0 | 895.0 | 766.0 | 714.0 | 612.0 | 489.0 | 0.0 | 641.0 | 542.0 | 600.0 |
| 400.0 | 1079.0 | 918.0 | 855.0 | 757.0 | 606.0 | 0.0 | 742.0 | 648.0 | 693.0 |
| 500.0 | 1260.0 | 1064.0 | 990.0 | 864.0 | 691.0 | 0.0 | 835.0 | 729.0 | 803.0 |
| 630.0 | 1493.0 | 1240.0 | 1154.0 | 993.0 | 794.0 | 0.0 | 950.0 | 828.0 | 918.0 |
|
Unenclosed spaced |
|
Unenclosed spaced from surface |
|
Unenclosed touching |
|
Enclosed conduit in air |
|
Enclosed, partially surrounded by thermal insulation |
|
Enclosed, completely surrounded by thermal insulation |
|
Buried direct |
|
Underground Wiring Enclosure |
|
Individual wiring enclosure |
VERSOLEX® 110 Flexible Single Core 110°C - Current carrying capacity table single phase (in Amps)
Insulation type: R-HF-110, R-E-110 OR X-HF-110
Maximum conductor temperature: 110°C
Reference ambient temperature: 40°C IN AIR, 25°C IN GROUND
| Conductor cross-section |
|
|
|
|
|
|
|
|
|
|---|---|---|---|---|---|---|---|---|---|
| mm² | Cu | Cu | Cu | Cu | Cu | Cu | Cu | Cu | Cu |
| 1.0 | 26.0 | 26.0 | 21.0 | 21.0 | 16.0 | 10.0 | 33.0 | 24.0 | 27.0 |
| 1.5 | 32.0 | 32.0 | 26.0 | 25.0 | 20.0 | 13.0 | 40.0 | 30.0 | 34.0 |
| 2.5 | 43.0 | 42.0 | 34.0 | 33.0 | 27.0 | 17.0 | 53.0 | 39.0 | 44.0 |
| 4.0 | 57.0 | 56.0 | 45.0 | 45.0 | 36.0 | 23.0 | 69.0 | 51.0 | 57.0 |
| 6.0 | 73.0 | 70.0 | 57.0 | 56.0 | 45.0 | 29.0 | 86.0 | 64.0 | 71.0 |
| 10.0 | 102.0 | 98.0 | 80.0 | 77.0 | 51.0 | 40.0 | 117.0 | 86.0 | 96.0 |
| 16.0 | 135.0 | 129.0 | 105.0 | 102.0 | 82.0 | 53.0 | 151.0 | 112.0 | 125.0 |
| 25.0 | 178.0 | 170.0 | 139.0 | 133.0 | 106.0 | 70.0 | 192.0 | 143.0 | 158.0 |
| 35.0 | 221.0 | 210.0 | 172.0 | 167.0 | 133.0 | 86.0 | 232.0 | 176.0 | 195.0 |
| 50.0 | 279.0 | 263.0 | 218.0 | 207.0 | 165.0 | 0.0 | 284.0 | 215.0 | 237.0 |
| 70.0 | 351.0 | 329.0 | 273.0 | 263.0 | 210.0 | 0.0 | 345.0 | 266.0 | 287.0 |
| 95.0 | 422.0 | 395.0 | 329.0 | 312.0 | 250.0 | 0.0 | 403.0 | 312.0 | 341.0 |
| 120.0 | 500.0 | 466.0 | 390.0 | 364.0 | 291.0 | 0.0 | 464.0 | 359.0 | 392.0 |
| 150.0 | 577.0 | 536.0 | 450.0 | 426.0 | 341.0 | 0.0 | 524.0 | 414.0 | 451.0 |
| 185.0 | 660.0 | 611.0 | 516.0 | 481.0 | 385.0 | 0.0 | 585.0 | 464.0 | 503.0 |
| 240.0 | 794.0 | 732.0 | 621.0 | 583.0 | 467.0 | 0.0 | 682.0 | 548.0 | 599.0 |
| 300.0 | 916.0 | 841.0 | 716.0 | 0.0 | 0.0 | 0.0 | 769.0 | 631.0 | 675.0 |
| 400.0 | 1105.0 | 1006.0 | 860.0 | 0.0 | 0.0 | 0.0 | 893.0 | 734.0 | 784.0 |
| 500.0 | 1290.0 | 1164.0 | 999.0 | 0.0 | 0.0 | 0.0 | 1009.0 | 855.0 | 909.0 |
| 630.0 | 1529.0 | 1359.0 | 1168.0 | 0.0 | 0.0 | 0.0 | 1154.0 | 977.0 | 1046.0 |
|
Unenclosed spaced |
|
Unenclosed spaced from surface |
|
Unenclosed touching |
|
Enclosed conduit in air |
|
Enclosed, partially surrounded by thermal insulation |
|
Enclosed, completely surrounded by thermal insulation |
|
Buried direct |
|
Underground Wiring Enclosure |
|
Individual wiring enclosure |
Our websites
Select your country to find our products and solutions
-
Africa
- Africa
- Ghana
- Ivory Coast
- Morocco
- North West Africa
- Americas
- Asia
- Europe
- Oceania
