Datolex® Screened security cable

Application

Suitable for use in control circuits associated with security systems including detection, monitoring and access control. Designed for use in ELV systems - 50V AC, 12V DC. Not suitable for mains connection.

Construction

Stranded bare copper conductor, PVC insulated, twisted pair, aluminium foil overall tape screened and stranded tinned copper drain wire, PVC sheathed.

• Sheath colour: BN Brown; GY Grey; WT White.
• Pack size: 1 – 100m spool; B – 300m box; C – 250m spool (JSC.5xx6C only); 5 – 500m spool; B2 – 200m box (JSC.5xx6C only).
• Insulation colours: 4C – Red, Black, White, Blue; 6C – Red, Black, White, Blue, Green, Yellow. 8C – Red, Blue, White, Black, Yellow, Green, Violet, Brown.
